HD-A504-2
Haida
Automatic Bursting Strength Testing Machine
Introduction:
Automatic bursting strength tester is the international general Miao Lun (Mullen) instrument, widely used in packaging materials, mainly used for the determination of all the cardboard and the single-layer and multi-layer corrugated cardboard, can also be used for silk, cotton and other non paper materials of bursting strength test. As long as put material, automatic testing, automatic detection, automatic oil return and automatic computation, storage test data, print, instrument with digital display and can automatically print the test results and data processing.
Design Standard:
JIS-L1004,L1018,L1031,K6328,P8131,P8112 ASTM-D2210,TAPPI T403,ISO2759-2001,GB/T1539
Uses:
Bursting strength tester is ideal for testing a wide range of materials like paper, paperboards, corrugated board and boxes, leather, filter cloth, rexine, ect, to determine their quality, strength and performance.
Paperboard bursting testing machine image
Automatic Bursting Strength Testing Machine
Introduction:
Automatic bursting strength tester is the international general Miao Lun (Mullen) instrument, widely used in packaging materials, mainly used for the determination of all the cardboard and the single-layer and multi-layer corrugated cardboard, can also be used for silk, cotton and other non paper materials of bursting strength test. As long as put material, automatic testing, automatic detection, automatic oil return and automatic computation, storage test data, print, instrument with digital display and can automatically print the test results and data processing.
Design Standard:
JIS-L1004,L1018,L1031,K6328,P8131,P8112 ASTM-D2210,TAPPI T403,ISO2759-2001,GB/T1539
Uses:
Bursting strength tester is ideal for testing a wide range of materials like paper, paperboards, corrugated board and boxes, leather, filter cloth, rexine, ect, to determine their quality, strength and performance.
Paperboard bursting testing machine image
It is applicable to test bursting strength for paperboard.
Advanced micro computer controller and digital processor ensure result precise.
Printer facility and fully detailed test reports.
Results of the tests are stored for viewing or for printing out as required.
User-friendly menu interface
Power protection ensure automatic record when power cut off.
It is applicable to test bursting strength for paperboard.
Advanced micro computer controller and digital processor ensure result precise.
Printer facility and fully detailed test reports.
Results of the tests are stored for viewing or for printing out as required.
User-friendly menu interface
Power protection ensure automatic record when power cut off.
Capacity : | High Pressure 0~100 Kg/ cm^2 (0.1kg/cm^2) |
Unit (switchable): | Kpa, psi, kg/cm^2 |
Accuracy: | 0.5% |
Pressure Range: | 250~5600kpa |
Speed of Compression: | High Pressure 170±10ml/min |
Specimen Clamping Force: | >690kpa |
Oil: | 85% Glycerin; 15% Distilled Water |
Sensing method: | Pressure Transmitter |
Indicating Method & Display: | LCD |
Material of the Ring | Stainless Steel: SUS304 |
Opening in Upper Clamp: | 31.5 0.05 mm Diameter |
Opening in Lower Clamp: | 31.5 0.05 mm Diameter |
Motor: | Anti-vibration Motor 1/8 HP |
Operation Method: | Automatic |
Dimension (LWH): | 445425525 mm |
Weight: | Approx. 70 kg |
Power: | AC220 10%, 50 Hz |
Power Capacity: | 120W |
Standard Configuration: | Rubber Membrane 1 piece, Spanner 1 set, Correction Shim 10 sheets, Glycerin 1 bottle |
Optional Configuration: | Printer, Air Pump |
The table parameters is for the company Standard Model parameters, we support customer customization parameters
