HD-A505S-1500
Haida
4 Load Cell Box Compression Test Machine
Product Introduction:
Carton packaging compression tester is the most direct test equipment for testing the compressive strength of carton or other packaging containers. Paperboard compression test equipment is used to judge the pressure resistance of the carton and can be used for the test of the pressure stacking. The test results can be used as the factory stacking finished product packaging. An important reference for the height of the box or an important basis for designing the package.
Applications
Package Compression Test Machine can make compression tests of packages (boxes) or packing and determine their piling up resistance (for storage and transport). These tests are called B.C.T. (Box Compression Test).
STANDARD FEATURES
Item | Description |
Max. Force | 2000kg/5000kg |
Load cell | 4 load cell for highest accuracy |
Control system | Windows 7, RS-232 interface |
Motor | Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod |
Force reading | kgf, Ibf, N, KN, T etc |
Load cell Resolution | 1/250,000 |
Load Precision | within ±0.25% |
Parallelism of Platens | Parallel within ±2.5mm |
Effective test area | 1300×1500×1500mm |
Test speed | 10 ±3mm/min (0.01~200mm/min adjustable) |
Software | TM 2101 |
Data display | Load, displacement, speed, loading rate and elapsed time |
Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
The Compression Testers Can Operate In Five Ways
1. Deformation under defined load: Test deformation under defined load of various corrugated cartons and beehive crates
2. Load under defined deformation: Test load under defined deformation of various corrugated cartons and beehive crates
3. Maximum load: test the maximum load of various corrugated cartons and beehive crates
4. Stacking test: stack test of various corrugated cartons and beehive crates
5. Cyclic test: dynamic strain according to strength & stroke
4 Load Cell Box Compression Test Machine
Product Introduction:
Carton packaging compression tester is the most direct test equipment for testing the compressive strength of carton or other packaging containers. Paperboard compression test equipment is used to judge the pressure resistance of the carton and can be used for the test of the pressure stacking. The test results can be used as the factory stacking finished product packaging. An important reference for the height of the box or an important basis for designing the package.
Applications
Package Compression Test Machine can make compression tests of packages (boxes) or packing and determine their piling up resistance (for storage and transport). These tests are called B.C.T. (Box Compression Test).
STANDARD FEATURES
Item | Description |
Max. Force | 2000kg/5000kg |
Load cell | 4 load cell for highest accuracy |
Control system | Windows 7, RS-232 interface |
Motor | Panasonic servo motor w/ DC variable speed drive system, high-precision mechanical ball screw rod |
Force reading | kgf, Ibf, N, KN, T etc |
Load cell Resolution | 1/250,000 |
Load Precision | within ±0.25% |
Parallelism of Platens | Parallel within ±2.5mm |
Effective test area | 1300×1500×1500mm |
Test speed | 10 ±3mm/min (0.01~200mm/min adjustable) |
Software | TM 2101 |
Data display | Load, displacement, speed, loading rate and elapsed time |
Safety features | E-Stop Over-load protection Upper and lower limit switches Load sensor with automatic retreat |
The Compression Testers Can Operate In Five Ways
1. Deformation under defined load: Test deformation under defined load of various corrugated cartons and beehive crates
2. Load under defined deformation: Test load under defined deformation of various corrugated cartons and beehive crates
3. Maximum load: test the maximum load of various corrugated cartons and beehive crates
4. Stacking test: stack test of various corrugated cartons and beehive crates
5. Cyclic test: dynamic strain according to strength & stroke
