Program Simulated Transport Box Vibration Testing Machine

Basic Standard: Following the ASTM International Transport Standard

Vibration function:
1. Frequency Modulation: any frequency within the frequency range of the (maximum acceleration <20g maximum amplitude <5mm)
2. Sweep function :( frequency / frequency / time range) can be arbitrarily set the standard really swept back and forth
3. Programmable functions: 15 each segment can be set (frequency / time) can be recycled
4. Frequency function: to increase in multiples of 15 segments, ① low to high frequency. ②. High to low frequency ③. Low to high and then low / recyclable
5. Logarithmic function:. ① low to high frequency ②. High to low frequency (the number of modes / cyclic)
6. The full-function computer controlled: with LCD computer and printer (with control, storage, recording function, print it) (optional)

Quantity:
  • HD-A521
  • HD

Program Simulated Transport Box Vibration Testing Machine


Products Overviews:

Package Vibration Tester is also called "Transport simulation shaking table", as ISTA test series package testing machine, simulation of automobile transportation jolting on package product damage, with the ability to identify whether to tolerate environmental vibration, which is suitable for box, package,electronic, electrical, optical, automobiles, toys... Research and development, quality control, manufacturing. vibration table is a test machine for improving the reliability of product quality


Features:

1. The digital screen dispaly the vibration frenquency

2. Use rail track for the installation of the test sample, oprate easily and safely

3. The pedestal of the machine applies heavy style channel with vibration attenuation pad, convenient, stable,no need to

    install the land-end screw.

4. Digital instrument display vibration frequency; synchronous belt transmission mute, very low noise

5.test items using clamping rail type, easy to operate, safe

6.machine using heavy-duty channel steel base with anti-vibration pad, easy installation, smooth operation

7.DC motor speed control, running smoothly, load capability; rotary vibration (commonly known as Valley-type)



Basic Standard: Following the EN71 ANSI、UL、ASTM、ISTA International Transport Standard


Vibration function:

1. Frequency Modulation: any frequency within the frequency range of the (maximum acceleration<20g maximum amplitude <5mm)

2. Sweep function :( frequency / frequency / time range) can be arbitrarily set the standard really swept back and forth

3. Programmable functions: 15 each segment can be set (frequency / time) can be recycled

4. Frequency function: to increase in multiples of 15 segments, ① low to high frequency. ②. High to low frequency ③. Low to high and then low / recyclable

5. Logarithmic function:. ① low to high frequency ②. High to low frequency (the number of modes / cyclic)

6. The full-function computer controlled: with LCD computer and printer (with control, storage, recording function, print it) (optional)


Control System:

1. Display: Taiwan high-precision digital meters

2. Precision: The frequency can be displayed to 0.01Hz

3. Precision: 0.1Hz

4. Time: 0.1min

5. Program capacity: a program group 120

6. n = 99 segments, each cycle can capacity 999 steps, each time setting a maximum of 99 hours 59 minutes

7. Other: Amplitude display acceleration (optional): To see the amplitude, acceleration, maximum acceleration



program simulated transport box vibration testing machine

Max. Test Load 100 Kg
Frequency Range 60-300 rpm
Amplitude Range 25.4 mm (1 inch)
Vibration Mode Roundtrip
Simulation Speed 25~40 km/h
Woke Table Size 1000×1200 mm
Outside Dimension (L×W×H) 1255×1070×660 mm
Power Capacity 1 HP
Weight 125 Kg
Environmental Conditions Temperature: 5~40°c;  Related Humidity: <85%
Speed Mode DC converter or AC Frequency Control

The table parameters is for the company Standard Model parameters, we support customer customization parameters
